The PRO-S 5KVA is an automatic servo voltage stabilizer built to safeguard high-demand electrical loads from the damaging effects of unstable mains voltage. Bridging the gap between a small voltage stabilizer and larger mainline units, it suits small workshops, commercial kitchens, telecom equipment rooms, and multi-device office setups. It accepts an input range of 140V – 276V and maintains a steady 230V output with an accuracy of ±1–1.5%, keeping critical equipment running reliably regardless of grid conditions.
Rated at 5KVA with a continuous output current of 20A, this servo voltage stabilizer is engineered for sustained heavy-duty operation — achieving up to 98% efficiency while advanced assembly technology actively limits heat build-up during prolonged use. A front-facing LCD screen delivers real-time visibility of input and output voltage, and the integrated protection system of this automatic voltage stabilizer guards against overvoltage, undervoltage, overload, short circuit, and overtemperature events. A 6-second safe-start delay is activated at every power-on cycle, preventing inrush stress on the connected load.
Compact enough for wall mounting yet robust enough for round-the-clock operation, the PRO-S 5KVA voltage stabilizer regulator holds CE, cULus, and TÜV Austria certifications — a dependable servo voltage stabilizer available across Egypt for residential, commercial, and light-industrial environments where power quality directly impacts productivity.
| Specification | Value |
| Rated input voltage | 230 Vac |
| Permissible input tolerance | +20% to −30% (140V – 276V) |
| Rated output voltage | 230 Vac |
| Output accuracy | ±1 – 1.5% |
| Rated power | 5 KVA |
| Rated current | 20 A |
| Frequency | 50 / 60 Hz |
| Efficiency | Up to 98% |
| Insulation class | Class H |
| Max ambient temperature | 50 °C |
| Protection index | IP23 Indoor |
| Test voltage | 3.5 KV |
| Dimensions (A × B × C) | 362 × 250 × 178 mm |
| Weight | 12.50 – 15.65 KG |
| Terminal | Screw type |
| Protection features | Safe Start · Over & Under Voltage · Overload · Short Circuit · Over Heat · Internal Bypass |
| Standards | IEC 61000 · IEC 61558 · IEC 62103 · IEC 60529 |
