The Single Phase Control Transformer is a 50 VA safety isolation transformer for swimming pool applications — the smallest and lightest model in the range. At just 1.5 kg and ultra-compact dimensions, it is designed for tight panel installations. It provides full galvanic isolation between 230 Vac mains and a safe 12 Vac output, fully compliant with IEC 61558 safety requirements for wet environments.
Outstanding Features
Ideal for LED lights and small sensor circuits
Designed for installation inside sealed control panels
Safe 230 Vac to 12 Vac isolation
1.5 kg for fast single-person installation
Fits very tight enclosure spaces
M5 base plate fixing for stable installation
98% efficiency with minimal losses
Built according to IEC 61558 standards
| Specification | Value |
|---|---|
| Rated Power | 50 VA |
| Input Voltage | 0 – 230 Vac |
| Output Voltage | 0 – 12 Vac |
| Frequency Range | 50–60 Hz |
| Efficiency | 98% |
| Enclosure Type | Open Type |
| Protection Index | IP00 |
| Insulation Class | Class H |
| Max Ambient Temperature | 50°C |
| Test Voltage | 3.5 kV |
| Fixing Method | Base Plate |
| Fixing Screws | M5 |
| Terminal Type | Screw Type Terminal |
| Weight | 1.5 kg |
| Dimensions | 76.2 × 83 × 79.5 × 53.5 × 49 × 5.5 mm |
| Standards | IEC 61558 |
